BVM W & Z Hinges - SS 1.5mm Matt
Product Overview
Specialized W and Z profile stainless steel hinges with 1.5mm thickness. W hinges provide multi-angle adjustment, Z hinges offer concealed mounting for clean aesthetics. Ideal for modular kitchen cabinets, wardrobe doors, and furniture requiring adjustable or concealed hinges.
Key Features
Material: Stainless Steel (SS 304)
Finish: Matt
Thickness: 1.5mm
Types: W Hinges (adjustable), Z Hinges (concealed)
Sizes: 3" (75mm) and 4" (100mm) with multiple width combinations
Applications: Modular kitchen cabinets, wardrobe doors, adjustable furniture
Corrosion Resistant: SS 304 construction
W Hinges: Multi-angle adjustment capability
Z Hinges: Concealed mounting for seamless look
Technical Specifications
Brand: BVM | Category: W & Z Hinges | Material: SS 304 | Finish: Matt | Thickness: 1.5mm | Sizes: W Hinges 3" (75×12×6, 75×12×12, 75×12×19, 75×12×25, 75×19×6, 75×19×12, 75×19×19, 75×19×25) and 4" (100×12×6, 100×12×12, 100×12×19, 100×12×25, 100×19×6, 100×19×12, 100×19×19, 100×19×25) | Z Hinges: 3"×1/2"×1/2", 3"×3/4"×3/4" | Packing: W Hinges 3" - 18 pcs/box, 4" - 16 pcs/box, 20 boxes/carton; Z Hinges - 20 pcs/box, 15 boxes/carton
What's Included
W or Z Hinges per selected type and size. Mounting screws not included.
Installation & Maintenance
W Hinges: Adjustable mounting for angle calibration. Z Hinges: Concealed mortise installation. Pre-drill pilot holes. Maintenance-free - wipe with soft cloth.
Warranty
12-Month Manufacturing Defects Warranty (per BVM policy)
